AD14PP3ALFS

3 comp air distributor with push pull seq

The Betts Air CommanderTM is a reliable universal air distribution system designed to control the operation of, but not limited to, air operated bottom discharge valves and vapor recovery systems on cargo tanks. The air distributor can be plumbed to function sequentially or non-sequentially and is versatile enough to satisfy a wide variety of uses.

• Compact Design
• Anodized Aluminum with Brass and Stainless Components
• Robust Snap-Action Toggles offer visual OPEN or CLOSE indication.
• Fluorosilicone Seals
• Pressure Indicator Slide
• Simple In Place Maintenance
• Temperature Range: **
-40°F to 180°F [-40°C to 82°C]
• Working Pressure: **
Min: 60 psi [2.8 bar]
Max: 125 psi [9 bar]

Air Commander Parts List
