5204
$381.58
73 in stock
4″ BOT LOADER W/SIGHT GLASS
Applications
- Used for bottom loading and unloading of petroleum tankers, Load/unload valve permits both terminal loading, and fuel unloading through the valve.
Specifications
- Manufactured to American Petroleum Institute standard API RP-1004, which allows for positive connection to drop adapters and rack couplers such as the Dixon Bayco 5300/5400 series rack coupler.
Features
- Unique fluid flow sight level
- Ergonomically curved handle operates on a short 62° degree stroke
- Any required maintenance is simplified, Dixon Bayco API Valves can be completely rebuilt without the need to remove the valve from the tanker
- Nose ring is anodized hard coat aluminum, which in most applications will provide years of trouble free service. Nose ring can be rotated to provide a fresh connection service.
Construction
- Aluminum body with anodized hard coat aluminum nose ring and stainless steel hardware
- Fixed aluminum handle
- Nylon sight glass
- Baylast™ seals
Warehouse Inventory
| Warehouse | Count |
|---|---|
| Wood River, IL | 6 |
| Converse, TX | 7 |
| Birmingham, AL | 5 |
| Atlanta, GA | 10 |
| Tampa, FL | 10 |
| Des Moines, IA | 25 |
| Billings, MT | 8 |
| Commerce City, CO | 2 |
