Blackmer TXD3E
Full Parts List
Part #
Description
Price
Qty
KIT
898958
TXD3E Maintenance kit FKM
$1,545.60
898952
TXD3E Maintenance kit
$1,272.60
1
413957
Relief valve cap
$53.42
2
431808
3"Relief valve adjusting screw
$11.21
3
922923
Lock nut adjusting screw
$1.86
4
411807
3" Relief valve cover
$148.68
5
920331
Capscrew r/v cover
$1.78
5A
920330
Cap screw r/v cover
$13.36
7
421805
3"Spring guide
$35.84
8
471806
RV Spring BV2A, 51-110 psi
$113.68
471809
TXD3 Relif valve spring 111-125
$182.28
9
451807
3" Relief valve
$147.00
451808
Valve
$135.24
10
531803
3"Relief valve gasket
$6.54
12
021805
TXD3E Pump body
$2,989.00
13A
261837
TXD3E Rotor and shaft
$2,982.00
14
091819
3" Standard Duravanes
$106.68
20
031815
3" Standard head
$489.72
20
031815
3" Standard head
$489.72
21
920369
Capscrew
$1.67
21
920369
Capscrew
$1.67
24
903172
3"Bearing
$98.28
24
903172
3"Bearing
$98.28
24A
903523
3" Bearing locknut
$30.91
24A
903523
3" Bearing locknut
$30.91
24B
903524
3" Bearing lock washer
$32.76
24B
903524
3" Bearing lock washer
$32.76
26
381817
3" Bearing cover gasket
$13.10
26
381817
3" Bearing cover gasket
$13.10
27A
041815
Bearing cover
$110.60
27A
041815
Bearing cover
$110.60
28
920285
CAPSCREW
$7.50
28
920285
CAPSCREW
$7.50
35
909178
Shaft key 3" pump
$5.87
42
651803
3"npt Flange
$89.88
42
651803
3"npt Flange
$89.88
42
655120
3" Flange X 3" VIC groove
$179.76
42A
381816
3" Flange gasket
$9.37
42A
381816
3" Flange gasket
$9.37
42B
920532
Flange Capscrew
$3.74
42B
920532
Flange Capscrew
$3.74
72
711938
3" Viton head oring
$65.52
701944
3", 3-1/2" Head oring Buna
$28.06
72
711938
3" Viton head oring
$65.52
701944
3", 3-1/2" Head oring Buna
$28.06
73
908198
Gage Plug
$4.03
76
317815
Grease fitting
$11.97
76
317815
Grease fitting
$11.97
76A
701992
Grease fitting
$13.10
76A
701992
Grease fitting
$13.10
77
121807
3" Push rod
$16.88
88
533908
3"Relif valve cap gasket
$7.48
104
331908
3"Grease seal
$16.88
104
331908
3"Grease seal
$16.88
186
341801
TXD3E Shaft protector
$24.36
LT
903091
Lock nut tool
$44.86
Full Parts List
Part #
Description
Price
Qty
153
331883
3" Mechanical seal assy, FKM
$307.44
331880
TX3 Mechanical seal assembly
$219.24
331873
3" Mechanical seal assy, PTFE
$417.48
153D
711931
Viton housing oring
$28.06
153L
701962
O-ring 2-224 FKM
$13.10
Full Parts List
Part #
Description
Price
Qty
42
651803
3"npt Flange
$89.88
42A
381816
3" Flange gasket
$9.37
42B
920532
Flange Capscrew
$3.74
42
655102
3" Weld flange for 3" pump
$266.91
42A
381816
3" Flange gasket
$9.37
42B
920510
Hex head cap screw 1/2-13 x 1 1/2
$2.17
42
655120
3" Flange X 3" VIC groove
$179.76
42B
920510
Hex head cap screw 1/2-13 x 1 1/2
$2.17
42C
702002
O-ring
$8.90
Full Parts List
Part #
Description
Price
Qty
1 1/4"
895140
TX3 hydraulic motor adapter kit 1-1/4"
$514.92
1"
895143
TXD3E hydraulic adapter kit 1" shaft
$490.56
26A
381817
3" Bearing cover gasket
$13.10
28A
920369
Capscrew
$1.67
34
906967
1-1/4" X 1-1/8" Coupling with set screw
$229.32
906990
1-1/8" X 1" Coupling with set screw
$238.56
35
909184
Key
$8.90
76
317815
Grease fitting
$11.97
76A
701992
Grease fitting
$13.10
135
041831
Hydraulic Motor Adapter-SAE A Flange
$278.04
135A
920510
Hex head cap screw 1/2-13 x 1 1/2
$2.17
